39
Chapter 2 Menu
INPUT CONFIGURATION C1
REMOTE C2
PASSWORD C3
SYSTEM CONFIGURATION C4
ON SCREEN SET C5
ALIGNMENT C6
WHITE UNIFORMITY C7
EXTEND MENU C8
INPUT SELECT
STANDBY MODE
DEFAULT CH
DEGAUSS DELAY
CONT/BRT HOLD
CONT/BRT CENTER
COL TEMP SHORT-CUT
The SYSTEM CONFIGURATION menu is used for
the following settings:
• Channel number entry method (INPUT SELECT
menu)
This menu sets the way in which the numeric keypad
can be used to enter channel numbers.
•Power-up condition (STANDBY MODE menu)
This menu sets the condition of the monitor when the
MAIN POWER switch on the rear panel is switched
on.
•Power-up input channel (DEFAULT CH menu)
This menu sets the power-up input channel.
•Time from power-up until degauss (DEGAUSS
DELAY menu)
If several monitors are turned on at the same time and
all start degaussing at the same time, there will be a
very large current draw on the power supply for a few
moments. To prevent this, the delay time between
power-up and degaussing can be set for each monitor
independently.
Overview
Structure of the SYSTEM CONFIGURATION Menu
[C4]
Setting the Channel Selection Method and Power-Up
Conditions (SET UP 4) — SYSTEM CONFIGURATION Menu
Level 1 Level 2
•Setting of the contrast and brightness after
adjusting the white balance (CONT/BRT HOLD
menu)
Selects if the adjusted contrast and brightness are
retained or they are reset to the center values.
•Setting of the center value of the contrast and
brightness (CONT/BRT CENTER menu)
Selects the center value (1000 or 0000) of the contrast
and brightness.
•Assigning shortcut to the COLOR TEMP ADJ
menu to the [F2] key (COL TEMP SHORT-CUT
menu)
Assigns the shortcut to the MANUAL menu of the
COLOR TEMP ADJ menu to the [F2] key. This
allows you to jump directly to the MANUAL menu
corresponding to the color temperature set to the
currently displayed image (STD/COL 1/COL 2/CH
SET).
To Next Page
