Chapter 2 Menu
Overview
Structure of the STATUS Menu
Setting Lists of the STATUS Menu
This section explains the setting lists displayed in the
menu.
How to read the setting lists
•For purposes of explanation, each setting list is
preceded by a menu number. These numbers are not
displayed on the screen.
For more information about the menu number, see “About
menu numbers” on page 16.
•The arrow mark (k) refers you to another setting
list that appears after you make the setting, or to an
operation that is carried out as a result of the setting.
When there is no arrow mark, the menu does not
have any sub-list.
[F] STATUS menu
Select the STATUS menu 1/2 or 2/2. k [F1]
[F1] STATUS menu (1/2)
Specify the channel block to be detected from channel
1 to channel 99.
[F11] CH STATUS menu
Data about the current channel is displayed.
CH: channel number
LN: input connector number
FORMAT: format of the input signal
CV: frame rate
NAME: channel name
[F2] STATUS menu (2/2)
Data about the monitor is displayed.
MODEL NAME: model name
SERIAL NO: serial number
OPERATION TIME: operation time (in hours)
SOFTWARE VERSION: software version
[F] Displaying Information About the Monitor
— STATUS Menu
The STATUS menu is used to view general data about
the monitor status, the current channel, etc.
The following information is displayed on the three
pages of the STATUS menu.
•Data about the current channel (STATUS menu
(1/2))
•Data about the monitor in use
(STATUS menu (2/2))
STATUS F
STATUS (1/2) F1
STATUS (2/2) F2
CH STATUS F11
MODEL NAME
CH
Main Menu Level 1 Level 2 Level 3
To Next Page
