Sony Trinitron BVM-F24E User Manual

57
Chapter 3 Appendix
Input/output connectors
Input connectors
RGB INPUT: BNC type × 3 (75-ohm)
0.7 Vp-p (1 Vp-p, sync on green),
+3 dB/−6 dB, positive
HD SDI: BNC type × 2 (75-ohm)
(Single × 2 or Dual × 1)
Output connectors
MONITOR OUT: BNC type × 2
Sync input connectors
COMP: BNC type (75 ohm),
0.3 to 5.0 Vp-p, positive/negative tri-
level sync signal input or negative bi-
level sync signal input
HD/VD (separate): BNC type (75 ohm),
0.3 to 5.0 Vp-p, positive/negative sync
signal input (selected automatically)
Remote control
OPTION: Mini-DIN 8-pin × 1
CONTROL UNIT: D-sub 9-pin × 1
REMOTE 1: D-sub 9-pin × 1 (with loop-
through output), RS-485 serial interface
REMOTE 2: D-sub 9-pin × 1
ISR: D-sub 9-pin × 1
Video signal
Frequency response
48 Hz to 90 MHz, +1 dB/ –3 dB
DC restoration
Black level fluctuation: less than 1% for
10 % to 90% APL input signal variation
Specifications
General
System 54 kHz – 91.1 kHz (For details, see
“Available Signal Formats” on page 60.)
CRT Super fine pitch Trinitron, flat surface,
16:9 aspect ratio
Aperture grille pitch: 0.25-0.28 mm
90 degree deflection, 29.1 mm diameter
in-line gun
Effective picture size with 16:9 aspect
ratio:
482.1 × 271.2 mm (19 × 10
3
/
4
inches)
(w/h)
553.1 mm (21
7
/
8
inches) (diagonal size)
Effective picture size with 5:4 aspect ratio:
361.6 × 271.2 mm (14
1
/
4
× 10
3
/
4
inches)
(w/h)
452.0 mm (17
7
/
8
inches) (diagonal size)
CRT protection: EHT (extremely high
tension) protection type
Warm-up time: approx. 30 minutes
Anode voltage: 27 kV with no beam
current
Nominal chromaticity coordinates:
SMPTE C phosphor
EBU phosphor
Error: ± 0.005 or less
Mass Approx. 54 kg (119 lb 1 oz)
Power consumption
225 W (max.)
Power requirements
100 to 240 V AC, 2.4 to 1.0 A, 50/60 Hz
Peak inrush current
(1) Power ON, current probe method:
50 A (230 V)
(2) Hot switching inrush current,
measured in accordance with European
standard EN55103-1
18 A (230 V)
xy
R 0.630 0.340
G 0.310 0.595
B 0.155 0.070
xy
R 0.640 0.330
G 0.290 0.600
B 0.150 0.060
Chapter 3 Appendix
