427
3
Enter a name of up to 8 characters in the keyboard
window, and press [Enter].
Setting the transition rate target to display
on memory recall buttons
This sets the memory recall button assignments in
transition rate display mode.
1
In the Engineering Setup >Panel >Prefs/Utility
>Utility Module Assign menu (7324.1), press [Trans
Rate Mode Assign].
The Trans Rate Mode Assign menu (7324.3) appears.
2
Select the target button to set.
3
Select the transition rate to assign.
4
Press [Set].
To release the assignment
Select the target button to release, then press [Clear].
Assigning Functions to Cross-Point
Buttons of the Cross-Point Control
Block
You can assign functions to the cross-point buttons of the
cross-point control block (utility/shotbox mode).
1
In the Engineering Setup >Panel >Prefs/Utility menu
(7324), press [Xpt Module Assign].
The Xpt Module Assign menu (7324.2) appears.
2
Select the target button to set.
3
In the
<Action> grou
p, select the fun
ction to assign.
Menu Shortcut: Assign a frequently used menu to be
recalled (menu shortcut).
Utility Command: Assign a function setting (utility
command).
Macro Recall: Assign a macro register recall.
Shotbox Recall: Assign a shotbox register recall.
4
Perform the following operations, according to the
selection in step 3.
When [Menu Shortcut] is selected: When a cross-
point button on the cross-point control block is
blinking, display the shortcut menu. Press the
target button to set to assign a shortcut. When
finished, press [Menu Shortcut] again.
When [Utility Command] is selected: Select a
command to assign in the list on the right side of
the status area.
a) For “DCU GPI Test Fire” only
When [Macro Recall] is selected: Select a macro
register to assign in the list on the right side of the
status area.
When [Shotbox Recall] is selected: Select a shotbox
register to assign in the list on the right side of the
status area.
5
Press [Action Set].
When [Menu Shortcut] is selected in step 3, it is not
necessary to press [Action Set].
To release the assignment
Select the target button to release, then press [Clear].
To display the register name in the status area list
When [Macro Recall] or [Shotbox Recall] is selected, you
can change the register number display to the register
name.
To display the register name, press [Reg Name Display],
turning it on.
For details about utility commands that can be assigned to
cross-point buttons, see “List of utility commands and user
preference button states” (page 422).
Settings names to show on the display
You can set the names to display when menu shortcuts or
utility commands are assigned to cross-point buttons.
When a macro register is assigned, the names specified in
the Macro menu are displayed on the display. When a
shotbox register is assigned, the names specified in the
Shotbox menu are displayed on the display.
No. Parameter Adjustment
1 Bank Bank selection
2 Button No Button selection
No. Parameter Adjustment
3 Command Utility command selection
4
a)
GPI No GPI number
No. Parameter Adjustment
3 Macro Macro register selection
No. Parameter Adjustment
3 Shotbox Shotbox register selection
Note
To Next Page
