Sungrow SG125CX-P2 User Manual

8 System Decommissioning User Manual
• Before dismantling the inverter, disconnect the inverter from both AC and DC
power sources.
• If there are more than two layers of inverter DC terminals, dismantle the outer
DC connectors before dismantling the inner ones.
• If the original packing materials are available, put the inverter inside them and
then seal them using adhesive tape. If the original packing materials are not
available, put the inverter inside a cardboard box suitable for the weight and size
of this inverter and seal it properly.
step 1 Refer to 5 Electrical Connection to disconnect all cables in reverse steps. In particular, when re
moving the DC connector, use a connector wrench to loosen the locking parts and install water
proof plugs.
step 2 Refer to4 Mechanical Mounting, to dismantle the inverter in reverse steps.
step 3 If necessary, remove the wall-mounting bracket from the wall.
step 4 If the inverter will be used again in the future, please refer to 3.2 Inverter Storage for a proper
conservation.
- - End
8.3 Disposal of Inverter
Users take the responsibility for the disposal of the inverter.
WARNING
Please scrap the inverter in accordance with relevant local regulations and standards
to avoid property losses or casualties.
108

Sungrow SG125CX-P2 Specifications

General

Max. DC Voltage	1100 V
Rated AC Power	125 kW
Max. DC Power	150 kW
Start-up Voltage	200 V
MPPT Voltage Range	200 V - 1000 V
Max. Short-circuit Current per MPPT	40 A
Max. AC Power	137.5 kW
Max. AC Current	198 A
Rated AC Voltage	400 V
Rated Grid Frequency	50/60 Hz
Total Harmonic Distortion	<3%
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
DC Connection Type	MC4
Protection Class	IP66
Maximum DC Input Power	150 kW
DC Inputs per MPPT	2
Cooling Method	Smart forced air cooling
Operating Temperature Range	-25°C to +60°C
Humidity Range	0 - 100%
Communication	RS485, Ethernet
