Sungrow SG125CX-P2 User Manual

User Manual 4 Mechanical Mounting
Rubber mallet Socket wrench set
(M4, M8, M12)
Open-end wrench
(16 mm, 33 mm)
Anti-static wrist strap
Wire cutter Wire stripper Hydraulic plier Heat gun
Crimping tool
4–6mm
2
Connector wrench Multimeter
≥ 1100 Vdc
RJ45 crimping tool
Vacuum cleaner Allen wrench Electric drill (φ12) Scissors
4.4 Moving Inverter
Before installation, remove the inverter from the packing case and move it to the installation
site.
It is recommended to use the four screw-in handles and the Bottom handles to move the
inverter. Attach the four screw-in handles to the inverter lugs and base. Lift and move the
inverter to its destination by means of the bottom handles and the four installed handles.
25

Sungrow SG125CX-P2 Specifications

General

Max. DC Voltage	1100 V
Rated AC Power	125 kW
Max. DC Power	150 kW
Start-up Voltage	200 V
MPPT Voltage Range	200 V - 1000 V
Max. Short-circuit Current per MPPT	40 A
Max. AC Power	137.5 kW
Max. AC Current	198 A
Rated AC Voltage	400 V
Rated Grid Frequency	50/60 Hz
Total Harmonic Distortion	<3%
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
DC Connection Type	MC4
Protection Class	IP66
Maximum DC Input Power	150 kW
DC Inputs per MPPT	2
Cooling Method	Smart forced air cooling
Operating Temperature Range	-25°C to +60°C
Humidity Range	0 - 100%
Communication	RS485, Ethernet
