Sungrow SG125CX-P2 User Manual

7 iSolarCloud App User Manual
The App icon appears on the home screen after installation.
7.3 Login
7.3.1 Requirements
The following requirements should be met:
• The AC or DC side of the inverter is powered-on.
• The mobile phone is within 5 meters away from the inverter and there are no obstructions
in between.
• The Bluetooth function of the mobile phone is enabled.
The inverter can only pair with one phone at a time through Bluetooth.
7.3.2 Login Procedure
step 1 Open the App to enter the login page, tap Local Access at the bottom of the page to go to the
next page.
step 2
Establish the Bluetooth connection by either of the two following ways. If the LED indicator flashes
blue, the connection is successfully established.
•
Scan the QR code on the side of the inverter for Bluetooth connection.
•
Tap "Manual connection" and select "Others" at the bottom of the page, the Bluetooth search
page will automatically pop up, and select the inverter to be connected according to the SN on
the nameplate on the side of the inverter body.
86

Sungrow SG125CX-P2 Specifications

General

Max. DC Voltage	1100 V
Rated AC Power	125 kW
Max. DC Power	150 kW
Start-up Voltage	200 V
MPPT Voltage Range	200 V - 1000 V
Max. Short-circuit Current per MPPT	40 A
Max. AC Power	137.5 kW
Max. AC Current	198 A
Rated AC Voltage	400 V
Rated Grid Frequency	50/60 Hz
Total Harmonic Distortion	<3%
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
DC Connection Type	MC4
Protection Class	IP66
Maximum DC Input Power	150 kW
DC Inputs per MPPT	2
Cooling Method	Smart forced air cooling
Operating Temperature Range	-25°C to +60°C
Humidity Range	0 - 100%
Communication	RS485, Ethernet
