2 Product Introduction User Manual
8
2.2.2 Dimensions of Inverter
Fig. 2-3 Outline Dimensions of Inverter (unit: mm)
2.2.3 LCD Display Panel
As a human-computer interaction interface, LCD display panel comprises LED
indicators, buttons and LCD display screen on the front panel of the inverter.
y
LEDs indicate the working status of the inverter
y
The current running information shown on the LCD display
y
Fault records shown on the LCD display
y
Inverter configuration by pressing the buttons
Fig. 2-4 LCD Display Panel
