User Manual 10 Operation of LCD Display
77
10.9.3 Load Default
All history information will be unrecoverable cleared and all parameters will
return to the default value except the protection parameters and time once
the “load default” operation is performed.
Main Screen(Press ENTER)→Menu screen(Press j×3)→Set-param(Press ENTER)
→Enter password(Press ENTER)→Sys-param(Press ENTER, Press j×3)→Load
default(Press ENTER)
A password confirmation screen will occur. Press h to
move cursor right and Press j to input the password
111111.
Press ENTER to confirm “load default”.
10.9.4 Firmware Version
Main Screen(Press ENTER )→Menu screen(Press j×3)→Set-param(Press
ENTER) → Enter password(Press ENTER) → Sys-param(Press ENTER, Press
j×4 )→Firmware version (Press ENTER)
Inverter shows detailed firmware information, including
LCD version and DSP version.
The firmware version information is read only.
