5-34 CHASSIS
BEARINGS
• Apply grease to the bearings before installing.
' 99000-25010: SUZUKI SUPER GREASE “A”
• Install new bearing and dust seal to the sprocket mounting
drum using the special tool.
% 09913-70210: Bearing installer set
• Apply grease to the bearing and dust seal lip.
' 99000-25010: SUZUKI SUPER GREASE “A”
• Install new wheel bearings using the special tool.
% 09941-34513: Bearing installer set
$
• Make sure that the brake disc is clean and free of any grease.
Apply THREAD LOCK SUPER “1360” to the brake disc bolts
and tighten them to the specified torque.
( 99000-32130: THREAD LOCK SUPER “1360”
# Brake disc bolt: 23 N·m (2.3 kgf-m)
• Apply SUZUKI SUPER GREASE to the rear sprocket mount-
ing retainer.
• Apply SUZUKI SUPER GREASE to the contacting surface
between the rear wheel and the sprocket drum.
' 99000-25010: SUZUKI SUPER GREASE “A”
First, install the right wheel bearing, then install the
spacer and left wheel bearing.
The sealed cover of the bearing must face outside.

Suzuki GSF650S Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Bore x Stroke	65.5 mm x 48.7 mm
Compression Ratio	11.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	6-speed constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Displacement	656 cm³
Front Brakes	Disc
Rear Brakes	Disc
Front Tire	120/70ZR17
Rear Tire	160/60ZR17
Fuel Tank Capacity	19 liters
Seat Height	790 mm
