2-120

BEFORE DRIVING

75RM0-01E

Right hand (A)

75RM338

Left hand (B)

75RM339

Right hand drive vehicle

To readjust the light pattern by masking the

headlight lens;

1) Copy the A and B templates as shown

in the below illustrations.

2) Transfer the template to a self-adhesive

waterproof material and cut it out.

3) Match the corner of the self-adhesive

template to the center mark of the

headlight lens as shown in the following

illustrations, and affix it.

Right hand (A)

75RM340

Left hand (B)

75RM341
