5-43

OTHER CONTROLS AND EQUIPMENT

75RM0-01E

Listening to the radio (Type A)

75RM082

(2)

(3)

(6)

(4)

(5)

(1)

EXAMPLE

Display

68LM561

(1) “RADIO” button

(2) UP button

(3) DOWN button

(4) “TUNE/FLD PUSH SOUND” knob

(5) PRESET buttons ([1] to [6])

(6) “AS” button

(A) Band

(B) Frequency

(A)

(B)
