INSPECTION AND MAINTENANCE

75RM0-01E

Air conditioner filter replacement

(if equipped)

Since special procedures are required, ask

your authorized SUZUKI dealer for this job.

75RM074

1) To approach the air conditioner filter,

remove the glove box. Press inward on

both sides of the glove box to unclamp

it.

75RM075

2) Remove the cover (1) and pull out the

air conditioner filter (2).

NOTE:

When you install a new filter, check that

the UP mark (3) faces upward.

EXAMPLE

(1)

(2)

(3)
