8-6
EMERGENCY SERVICE
75RM0-01E
IMPORTANT
The flat tire repair kit cannot be used in
the following cases. Consult a SUZUKI
dealer or a roadside assistance service.
• Cuts or piercing in the tire tread
larger than approx. 4 mm.
• Cuts in the tire side wall.
• Tire damage caused by driving with
considerably reduced tire pressure or
even with deflated tire.
• The tire bead completely unseated
outside of the rim.
• The rim damaged.
Small punctures in the tire tread,
caused by a nail or a screw, can be
sealed with the flat tire repair kit.
Do not remove nails or screws from the
tire during an emergency repair.
Flat tire repair kit contents
81P70030
(1) Air compressor
(2) Sealant bottle
(3) Filler hose
(4) Valve insert remover
(5) Valve insert (spare)
(6) Speed restriction sticker
WARNING
Flat tire repair kit sealant is harmful if
swallowed, or if it comes in contact
with skin or eyes. If swallowed, do
not induce vomiting. Give plenty of
water (if possible charcoal slurry)
and seek medical attention immedi-
ately. If sealant gets in eyes, flush
eyes with water and seek medical
attention. Wash thoroughly after han-
dling. Solution can be poisonous to
animals. Keep out of the reach of
children and animals.
NOTICE
Replace the sealant before expiry
date indicated on the label of the
sealant bottle. To purchase new seal-
ant, see your SUZUKI dealer.
To Next Page
