3-54

OPERATING YOUR VEHICLE

75RM0-01E

Frontal collision warning

When there is a risk of a frontal crash, a warning will be given through the information dis-

play and sound.

75RM282

Warning brake system

If the driver cannot take or is insufficient to take evasive action such as brake operation

and steering operation after frontal collision warning activates, the system applies brake

lightly.

75RM283

EXAMPLE

buzzer

with tachometer

without

tachometer

Information display

EXAMPLE

buzzer

with tachometer

without

tachometer

Information displayIndicator

light

Modification Warning4
