5-8

OTHER CONTROLS AND EQUIPMENT

75RM0-01E

75RM138

There is a recess in the glove box.

WARNING

Never drive with the glove box lid

open. It could cause injury if an acci-

dent occurs.

Cup holder and storage area

75RM297

(1) Center console tray (2) Front cup holders

(3) Front bottle holder (4) Front seat back pocket (if equipped)

(5) Rear cup holder (6) Rear bottle holder

(1) (2) (3) (6)(4)

(6)(5)(3)

(4)

EXAMPLE
