11-3

SPECIFICATIONS

75RM0-01E

ITEM: Lights WATTAGE BULB No.

Headlight Halogen headlight 12V 60/55W H4

LED headlight LED –

Front fog light (if equipped) 12V 19W H16

Position light 12V 5W W5W

LED –

Daytime running light (if equipped) 12V 13W P13W

LED –

Turn signal light Front 12V 21W WY21W

Rear 12V 21W WY21W

Side turn signal light 12V 5W –

LED –

Tail/brake light 12V 21/5W W21/5W

LED –

High mount stop light LED –

Reversing light 12V 16W W16W

License plate light 12V 5W W5W

Rear fog light (if equipped) 12V 21W W21W

Interior light Front 12V 10W –

Luggage compartment

(if equipped)

12V 5W W5W
