Suzuki LT-F500F 2002 User Manual

CHASSIS 7-15
• Clean the front drive shaft.
• Remove the boot bands of the differential side joint (double
offset joint).
• Slide the boot toward to the center of the front drive shaft and
remove the stopper ring from the outer race.
• Separate the outer race from the front drive shaft.
• Wipe off grease and remove the snap ring from the drive
shaft.
• Remove the cage.
