CHASSIS 7-21
BRAKE FLUID REPLACEMENT
• Place the vehicle on a level surface and keep the handlebar
straight.
• Remove the master cylinder reservoir cap and diaphragm.
• Suck up the old brake fluid as much as possible.
• Fill the reservoir with new brake fluid.
' Specification and classification: DOT 4
• Connect a clear hose to the air bleeder valve and insert the
other end of the hose into a receptacle.
• Loosen the air bleeder valve and pump the brake lever until
the old brake fluid is completely out of the brake system.
• Close the air bleeder valve and disconnect the clear hose. Fill
the reservoir with new brake fluid to the upper end of the
inspection window.
$
BRAKE CALIPER REMOVAL AND
DISASSEMBLY
• Remove the front wheel. (!7-11)
• Disconnect the brake hose from the brake caliper by remov-
ing the brake hose union bolt
1 and allow the brake fluid to
drain into a suitable receptacle.
• Remove the brake caliper by removing the brake caliper
mounting bolts
2.
• Remove the brake pads. (!7-20)
&
* Never reuse the brake fluid left over from previous
servicing and which has been stored for long peri-
ods of time.
* Bleed air from the brake system.
(!2-17)
Brake fluid, if it leaks, will interfere with safe running
and discolor painted surfaces. Check the brake hose
and hose joints for cracks and oil leakage.
