7-44 CHASSIS
• Remove the steering shaft holder bolts.
$
• Remove the steering shaft
0.
• Remove the dust seals
A from the steering shaft.
• Remove the dust seal
B and O-ring
C from the frame.
$
INSPECTION
Inspect the removed parts for the following abnormalities.
* Handlebar distortion
* Handlebar clamp wear
DUST SEALS AND O-RING
Inspect the dust seals and O-ring for wear or damage. If any
damages are found, replace the dust seals with new ones.
TIE ROD
Inspect the tie rod for distortion or damage. If any damages are
found, replace the tie rod with a new one.
TIE ROD END
Inspect the tie rod end and boots for smooth movement. If there
are any abnormalities, replace the tie rod end with a new one.
Replace the removed clips with new ones.
Replace the removed O-ring with a new one.
