CHASSIS 7-83
CABLE PLAY ADJUSTMENT
PARKING INTERLOCK CABLE
Before adjusting the parking interlock cable play, adjust the rear
brake pedal height and rear brake lever play properly. (!2-
15)
• Shift the shift lever into “D”.
• Loosen the locknuts
1.
• Tighten the locknuts
1 with pulling the parking inter lock
cable
2 lightly.
• Make sure that the shift lever could be shifted into “P” when
the rear brake pedal is depressed approx. 20 mm (0.78 in).
