7-34 CHASSIS
• Remove the front grip lower cover. (!7-4)
• Remove the front grip mounting bolts for helping to remove
the lower wishbone arm mounting bolt.
• Loosen the upper wishbone arm pivot bolts/nuts and lower
shock absorber mounting bolt/nut.
• Remove the upper wishbone
1.
• Loosen the lower wishbone arm pivot bolts/nuts.
• Remove the lower wishbone
2.
• Loosen the engine coolant reservoir mounting bolt.
• Remove the upper shock absorber mounting bolt.
• Remove the shock absorber.
