CHASSIS 7-53
• Remove the spring
3 and insulator 4.
• Remove the brake caliper holder
5 and rubber parts 6.
• Place a rag over the brake caliper pistons to prevent them
from popping out and then force out the pistons using com-
pressed air.
$
• Remove the dust seal and piston seal.
$
Do not use high pressure air to prevent brake caliper
piston damage.
Do not reuse the dust seal and piston seal to prevent
fluid leakage.
