Illustrated table of contents
Exterior
(1) Door locks (P.3-2)
(2) Side turn signal light on outside rear-
view mirrors (if equipped) (9-44)
(3) Outside rearview mirror (P.2-10)
(4) Side turn signal light on fender
(if equipped) (P.9-47)
(5) Front camera (DSBS II) (P.5-61)
(6) Windshield wiper (P.3-28, 9-51)
(7) Engine hood (P.7-4)
(8) Fuel filler cap (P.7-1)
(9) Rear window wiper (P.3-28, 9-51)
(10) Radio antenna (P.7-32)
(11) High-mount stop light (P.9-47)
(12) Rearview camera (P.5-145)
(13) Tailgate (P.3-6)
(14) Position light and Daytime Running
Light (D.R.L.) (P.3-24, 9-45)
(15) Headlight (P.3-21, 9-44)
(16) Front turn signal light (P.3-26, 9-45)
(17) Front radar (DSBS II) (P.5-61)
(18) Towing eye cover (P.10-3)
(19) Reversing light (P.9-47)
(20) Brake light (P.9-47)
(21) Tail light (P.9-47)
(22) Rear turn signal light (P.3-26, 9-47)
(23) Parking sensor (P.5-136)
(24) Rear fog light (P.3-25, 9-49)
(25) License plate light (P.3-21, 9-49)
69T010010
(15)
(16)
(1) (2) (3) (4) (7)
(5) (6)
(14)
(8) (9) (10)(11) (12) (13)
(17) (18)
(19)
(20)
(22)
(23) (23)(24)
(25)
(21)
