INSPECTION AND MAINTENANCE
69TB-01E
Bulb replacement
NOTE:
If it seems to be difficult to perform bulb replacement, consult an authorized Suzuki dealer
or a qualified workshop.
69T090180
(11)
(1)
(2)
(3)
(9)
(8)(7)
(5)(6) (10)
(4)
(12)
If you need to replace the following bulbs
indicated in the above table, consult an
authorized SUZUKI dealer or a qualified
workshop.
No. ITEM: Lights
WATT-
AGE
BULB
No.
(1) Headlight
*1
LED –
(2)
Position light
and Daytime
Running Light
(D.R.L)
*1
LED –
(3)
Turn sig-
nal light
Front
12V
21W
WY21W
(4) Rear
12V
21W
PY21W
(5)
Side turn
signal light
*1
12V 5W –
(6) LED –
(7) Brake light
*1
LED –
(8) Tail light
*1
LED –
(9) Reversing light
12V
16W
W16W
(10)
High mount stop
light
*1
LED –
(11)
License plate
light
*1
LED –
(12) Rear fog light
12V
21W
P21W
