9-26
INSPECTION AND MAINTENANCE
69TB-01E
69T090020
Check the coolant level at the reservoir
tank, not at the radiator. With the engine
cool, the coolant level should be between
“FULL” and “LOW” marks.
If the coolant level is below “LOW” mark,
coolant should be added. While the engine
is cool, remove the reservoir tank cap and
add coolant until the reservoir tank level
reaches “FULL” mark. Never fill the reser-
voir tank above “FULL” mark.
Coolant replacement
Since special procedures are required, ask
an authorized SUZUKI dealer or a qualified
workshop for this job.
Air cleaner
If the air cleaner is clogged with dust, there
will be greater intake resistance, resulting
in decreased power output and increased
fuel consumption.
69T090030
1) Unclamp the clamps (1).
2) Hold up the air cleaner upper case.
3) Remove the element from the air
cleaner case. If it appears to be dirty,
clean or replace it with a new one.
4) Reinstall the air cleaner case securely.
NOTICE
• SUZUKI LLC: Super (Blue) coolant;
This coolant is already diluted to
the proper percentage. Do not
dilute with distilled water addition-
ally. Doing so may result in the pos-
sibility of freezing and/or
overheating coolant.
• SUZUKI LLC: Standard (Green)
coolant;
– The mixture you use should con-
tain 50% concentration of anti-
freeze.
– If the lowest ambient temperature
in your area is expected to be –
35°C (–31°F) or below, use higher
concentrations up to 60% follow-
ing the instructions on the anti-
freeze container.
NOTICE
When putting the cap on the reser-
voir tank, line up the mark on the cap
and the mark on the tank. Failure to
follow this can result in coolant leak-
age.
(1)
(1)
