9-51
INSPECTION AND MAINTENANCE
69TB-01E
69T090340
(3) Removal
(4) Install
2) Pull the bulb (5) out and then insert a
new one.
3) After replacing the bulb, install the lug-
gage compartment light lens in the
reverse order of removal.
Wiper blades
59RN09450
If the wiper blades become brittle or dam-
aged, or make streaks when wiping,
replace the wiper blades.
To install new wiper blades, follow the pro-
cedures below.
NOTE:
Some wiper blades may be different from
the ones described here depending on
vehicle specifications. If so, consult an
authorized SUZUKI dealer or a qualified
workshop for proper replacement method.
For windshield wipers:
69T090350.
1) Hold the wiper arm away from the win-
dow.
(3)
(4)
(5)
NOTICE
To avoid scratching or breaking the
window, do not let the wiper arm
strike the window while replacing the
wiper blade.
NOTICE
When raising both of the front wiper
arms, pull the driver’s side wiper arm
up first.
When returning the wiper arms, lower
the passenger’s side wiper arm first.
Otherwise, the wiper arms may inter-
fere with each other.
To Next Page
