SystemAir Geniox 12 User Manual

4
| General descriptions, dangers and warnings
Position Description
Symbol
3
Damper - supply air
4
Filter - supply air
5
Fan- supply air
6
Heating battery - supply air
7
Fan - extract air
8
Heat exchanger
9
Filter – extract air
10 Damper – extract air
11
Integrated control system in a cabinet behind this inspections door.
D.1.2 Weight of each section and production number – example for the Geniox unit
Weight of the section. Production number of the unit.
Number of the section in the unit.
Product name in this example Geniox 27SL, where 27 in-
dicates the size of the unit. The unique production num-
ber for the complete unit in this example is 1712–
0004601640–10 where 17 indicates production year
2017 and 12 indicates month.
D.1.3 CE label — example for the Geniox unit
CE marking is printed on the machine card.
output |

SystemAir Geniox 12 Specifications

General

Brand	SystemAir
Model	Geniox 12
Category	Air Handlers
Language	English
