9-3

| Speed control for rotor and assembly of divided rotor

9.1.3 Copy of the label with information about connection of cables

This self-adhesive label is always placed on the cover of the cabinet. The text is always in English.

9.2 Assemble the Systemair casing for Geniox 22, Geniox 24 and Geniox 27

Size

A B C

Geniox 22 2170 1640 520

Geniox 24 2320 1790 588

Geniox 27 2520 1940 588

Size Quantity

Length (mm)

Geniox 22 4 1014

Geniox 24

4 1164

Geniox 27

4 1314

output |
