44
| Adjustment and maintenance operations
Size of unit
Numbers and sizes of frames for bag filters (WxH)
10
1x[792x392]
11
2x[490x490]
12
1x[592x490] + 1x[490x490]
14
2x[490x592] + 1x[287x592]
16
3x[490x592]
18
2x[490x392] + 4x[592x392]
20
3x[592x592] + 3x[287x592]
22
6x[592x490] + 2x[287x490]
24
3x[592x592] + 1x[490x592]+ 3x[592x490] + 1x[490x490]
27
2x[592x592] + 8x[490x592]
29
6x[592x592] + 4x[490x592]
31
5x[592x592] + 5x[490x490] + 5x[592x287]
Note:
Special sizes of filters are available from Camfil.
Dept of filter frame must be 25 mm to ensure a complete airtight sealing around the AHU filter frame
R.4.2 Panel filters – the number of filters and the sizes of the frames
Size of unit
Numbers and sizes of frames for panel filters (WxHxD)
10
1x[792x392x48]
11
2x[490x392x48]
12
1x[490x490x48] + 1x[592x490x48]
14
2x[490x592x48] + 1x[287x592x48]
16
3x[490x592x48]
18
2x[490x392x48] + 4x[592x392x48]
20
3x[592x592x48] + 3x[592x287x48]
22
6x[592x490x48] + 2x[287x490x48]
24
3x[592x592x48] 4x[490x592x48] + 1x[490x490x48]
27
2x[592x592x48] + 8x[490x592x48]
29
6x[592x592x48] + 4x[490x592x48]
31
5x[592x592x48] + 5x[592x490x48] + 5x[592x287x48]
Note:
Special sizes of filters are available by Camfil.
R.4.3 Bag filters
Turn the unit off and wait for 2 minutes till unit completely stops. Used filters can be pulled out. Store the used filters
immediately in plastic bags to avoid that dust pollutes the environment. Geniox units in the sizes 10 – 31 are provided
with a very corrosive-resistant and reliable system, where filters are slid into the units in a lower and upper durable u-
profile of plastic/rubber Check the upper and lower U-profile for damage and check the vertical rubber profile on the
back wall as well as the rubber profile on the inspection door for damage. The new filter bags must be pushed carefully
into the unit in order to ensure that they are sealed properly. The filters must have vertical bags.
