Assembly of base frame – height 118 mm for unit sizes 20 – 31 |
5-1
Annex 5 Assembly of base frame – height 118 mm for unit sizes 20 – 31
A = Corner
B = Splice
C = Spacer
C = Length profile
D = End profile (width of base frame)
D1 = Middle profile
5.1 Base frame length 482– 2564 [mm] Unit size 20 – 31
End profile type D (width of base frame)
Unit size Quantity
Length [mm]
Geniox20 2 2070
Geniox22 2 2270
output |
