TCS 3000 User Manual

14
Total Control Systems www.tcsmeters.com
Configure Select Type: Red Lion LD, Omega & Tekinno displays are currently the only
external displays supported today
Address: Display Address from 1 to 99 and press ENTER
Display Data Choose the information to display on External Display and press
ENTER
- Delivery Gross
- Delivery Net
- Delivery Volume
- Delivery Total (Currency)
- Flow Rate
- Mass
Test This is a test sequence of numbers to exhibit on external display
AIR ELIMINATOR
The Air Eliminator is for the electronic actuation of a solenoid exhaust vent and a down
stream valve, when a level sensor switches.
AE Enable/Disable Enable or disable for operation
AE Detection Select Normally Open or Closed for level sensor detection
AE Relay Enable or disable exhaust vent solenoid valve actuation
PULSE OUTPUT
The solid state pulse frequency transmission of a scalable pulse factor
++ May require a 1K ohm pull down resistor to bring pulse to ground (0Vdc) ++
Enable/Disable Enable or disable operation
Configure Sets the DEFAULT for pulse transmission output data
Delivery Total (Currency)
Gross Volume
1 (1 pulse per unit)
1.1 (10 pulses per unit)
1.11 (100 pulses per unit)
1.111 (1000 pulses per unit)
Net/Gross Auto Detect Volume
1 (1 pulse per unit)
1.1 (10 pulses per unit)
1.11 (100 pulses per unit)
1.111 (1000 pulses per unit)
Pulse Repeater repeats the incoming pulse value
Startup Reset Enable or disable and press ENTER
RFID READER
Radio Frequency Identification (RFID) is for fixed location or fleet refueling.
++ requires the a database uploaded to the TCS 3000 register for this option to be used ++
External External is used for remote mobile readers
ThingMagic ThingMagic is for fixed reader locations
