TCS 3000 User Manual

22
Total Control Systems www.tcsmeters.com
EXTERNAL Continued.
EXAMPLE: GTP Viper Injector pump will dose every 5 Gallons.
Without an additive injection dose within the first 5 gallons, the
minimum PPM threshold will stop the delivery).
PISTON A pulsing positive signal output is provided during product delivery.
INJECTION RATIO - Enter desired Parts Per Million volume target.
INJECTION LIMITS - Enable/Disable Injection Limit for delivery shutdown.
Enter Minimum PPM value to end delivery
Enter Maximum PPM value to end delivery
Enter Additive Injection Stabilization Volume to stabilize the PPM ratio
at the beginning of a delivery.
INJECTION CALIBRATION
CALIBRATE - Automatically Calibrates the Additive Injector Pump
1) Begin calibration by pressing Enter
2) Enter volume on volumetric beaker.
NOTE: UNAVAILABLE AT THIS TIME
EDIT/VIEW PARAMETERS - Manually Calibrate the Additive Injector
AI Pulses/Unit (Enter Pulses per mL)
AI Pulser Type - Dual or Single
AI Min. Inj. Period - Time required for injection (mS)
PRESSURE An additive injection signal output for an injection pump, additive meter
and controlling the injection ratio with a control valve during delivery.
INJECTION RATIO - Enter desired Parts Per Million volume target.
INJECTION LIMITS - Enable/Disable Injection Limit for delivery shutdown.
Enter Minimum PPM value to end delivery
Enter Maximum PPM value to end delivery
Enter Additive Injection Stabilization Volume to stabilize the PPM ratio
at the beginning of a delivery.
EXAMPLE: A startup of a constant pressure injection pump will
immediately be out of tolerance, so a injection stabilization will
be required to allow the system to meet its target.
INJECTION CALIBRATION
CALIBRATE - Automatically Calibrates the Additive Injector Pump
1) Begin calibration by pressing Enter
2) Enter volume on volumetric beaker.
NOTE: UNAVAILABLE AT THIS TIME
EDIT/VIEW PARAMETERS - Manually Calibrate the Additive Injector
AI Pulses/Unit (Enter Pulses per mL)
AI Pulser Type - Dual or Single
AI Min. Inj. Period - Time required for injection (mS).
EXAMPLE: A typical minimum value of 600 mS is
needed for the injection control valve to maintain
consistent injection rate.
