WATER SENSOR
Allows you to program the maximum and minimum capacity of the Water sensor to read correctly. Water
sensor settings should be have a 0 PPM at 4 mA Minimum and 50 PPM at 20mA for Maximum .
View/Edit 1) Minimum Concentration Water PPM Input
2) Minimum Output Current mA Entry
3) Maximum Concentration Water PPM Input
4) Maximum Output Current mA Entry
NOTE: Settings will be Current (mA) Only
Unit Choose the Unit of Measure: PPM
DENSITY SENSOR
Allows you to program the maximum and minimum capacity of the Density sensor for correct
measurement.
View/Edit 1) Minimum Density per Unit of Measure Input
2) Minimum Output Current mA Entry
3) Maximum Density per Unit of Measure Input
4) Maximum Output Current mA Entry
NOTE: Settings will be Current (mA) Only
Unit Choose the Unit of Measure: lbs/GAL, kg/M3, kg/L, lbs/UKG, lbs/ft3, lbs/in3, lbs/floz, oz/floz
INTERLOCK
Allows you to use the Emergency Stop terminal on the 1, 3 and 8 channel communication expansion
boards. Requires an external switch for actuation.
Enable/Disable Enable or disable for operation
LAMP INDICATOR
Allows you the use of External Lamps to indicate Water Sensor warnings.
Lamp Enable/Disable Enable or disable for operation. If enabled, you must reboot the register for the settings
to be recognized.
Lamp Test Select from OK, Warning, Alert, Sensor Low, Sensor High, Stop Alarm, Sensor Fail and
Lamp off to verify testing.
NOTE: if you have not rebooted the TCS 3000 register after Enabling operation, the Lamp Test will not
operate correctly.
Lamp Address Assign the address of each Lamp Indicator.
To Next Page
