Page #20 background imageLoading...
Page #20 background image
20
Total Control Systems www.tcsmeters.com
Mass Density To provide a manual calculated Mass value, determine the value to input Mass
Density and press ENTER. NOTE: only provide value if not using a Densitometer.
Mass = Weight per Volume
Pump Control & Timing Enable/Disable Pump Control and select ENTER.
- Pump is an Optional Output Control
- Enabled means that the pump control will energize a PTO or Hydraulic Drive
during a truck delivery.
- Disabled means that the pump control is not active and will not energize.
Pump Speed Control 1 is a solid state voltage output signal based on a flow
rate setting. Flow rate setting of zero (0) is disabled. Utilizes the Pump Starter
terminal. NOTE: Pump Speed Control overwrites the Additive Pump setting.
Pump Speed Control 2 is a solid state voltage output signal based on a flow
rate setting. Utilizes the Reset terminal. Flow rate setting of zero (0) is
disabled.
Pump Starter to enter the Start Duration time in seconds for pump to energize
while the preset valves (S1 & S2) stay closed, then press
ENTER.
Pump Starter Advance is Not available at this time.
Pump Stabilization is used to enter how long you wish the Pump Starter
stays powered. Enter value in Seconds and press ENTER.
Valve Type
Select whether you are using a Single or Dual Stage Valve and press ENTER.
- A SINGLE Stage valve will energize valve with Solenoid 2.
- A DUAL Stage valve will energize valve with Solenoids 1 and 2.
1101 Both S1 and S2 energize at the beginning of delivery and near the end of the
delivery S1 shuts off and S2 is still operating.
1001 At the beginning of the delivery the S1 valve opens energizes while the S2
remains closed. When the preset slow flow bypass begins, the S1 valve closes
and the slow flow bypass valve S2 opens until the end of the delivery.
S1 - S2 Delay Timing of the S1 valve opening at the start of a delivery. Enter S1 time value
(minimum of 3 seconds).
Maximum Flowrate Input the maximum rated flow of flow meter and press ENTER.
NOTE: this value is critical to the Valve actuation!
S2 Flow Timing of the S2 valve closure rate. Enter S2 time value (minimum 0.3 seconds).
Unit of Measure
Gram/cm3 Gram/Cubic Centimeter
Gram/m3 Gram/Cubic Meter
Kilogram/m3 Kilogram/Cubic Meter
Milligram/m3 Milligram/Cubic Meter
Pound/ft3 Pound/Cubic Foot
Pound/in3 Pound/Cubic Inch
Ton/yard3 Ton/Cubic Yard
