Weights & Measures Settings
NOTE: The Calibration bolt must be removed in order to enter calibration mode. To remove the bolt, unscrew the bolt
with a 3mm Hex drive. Place calibration plate and screw in a safe location where it will not be lost. Under the calibration
plate you will find a screw. Using the 3mm Hex drive, loosen the calibration screw. You do not need to remove this
screw all the way.
*If you lose the calibration screw, you will not be able to operate the register.*
DO NOT LOSE THIS CALIBRATION SCREW
BEFORE YOU CALIBRATE THE REGISTER YOU MUST ENTER A PRODUCT
To Calibrate begin in section ADD NEW on Page 23.
*NOTE: ALL PRODUCTS MUST BE CALIBRATED INDIVIDUALLY *
PRODUCTS
RECALIBRATE PRODUCT
SELECT PRODUCT Highlight the product you want to re-calibrate and select ENTER.
NOTE: If you need to modify the settings you originally selected for the calibration of a product select
MODIFY PARAMETERS, if the settings were correct and you do not need to change them
select BEGIN RECALIBRATION.
A) Modify Parameters
Product Name Using the keypad type in the name of the product you are calibrating. If
the product listed is correct select ENTER. To change the product name
press Enter and input name as desired. The menu screen will provide instruct
tions on how to input your Alpha-Numeric keys.
Compensation Table Choose the correct Volume Temperature Compensation Table and press
ENTER.
Comp. Table Param. Input the correct Compensation Table Parameter and press ENTER. See
following tables for reference. NOTE: this list references most common
products, not an exhaustive list of every volume correction.
NONE No volume compensation will be corrected.
LINEAR_15C Input the product specific Coefficient of Expansion to 15C
LINEAR_20C Input the product specific Coefficient of Expansion to 20C
LINEAR_60F Input the product specific Coefficient of Expansion to 60F
See TABLE 2 for reference.
API TABLES 6B, 24, 54, 54B, 54E
See TABLE 3 for reference.
Default Used for standard register mode
MR1 Used for database
RPA1 Mode Used for remote programming
User DB Update Used to update the database. A portable USB memory drive loaded only with a factory
database file must be uploaded through the USB terminal located within the Register.
To Next Page
