Advanced
6.16 Quality of Service (QoS)
Quality of Service (QoS) is a network standard that assigns the priorities of traffic that
passes through your Wireless Gateway. This ensures that demanding real-time
applications, such as video streaming, are given priority over other data.
6.16.1 Queue Management
This page allows you to enable QoS and choose Differentiated Services Code Point
(DSCP) markings to automatically mark incoming traffic without reference to a
particular classifier.
To access the Queue Management page, click ADVANCED > Quality of Service >
Queue Management or click the Queue Management button.
Enable QoS — Check this box to enable the QoS feature.
Default DSCP Mark — Select a DSCP mark from the drop-down list. The DSCP mark is
used to classify and prioritize types of packets.
NOTE:
If the drop-down lit does not contain the DSCP marking that you want, select either
Private DSCP value or Public DSCP value.
Default Rate — Check the Auto box to set the rate to its auto default or uncheck the
box to enter the QoS rate manually.
Click the Apply button to save and apply the QoS settings.
6.16.2 Queue Config
This page allows you to configure a QoS queue entry and assign it to a specific
network interface. Each of the queues can be configured for a specific precedence.
The queue configuration will be used in Queue Classification to place ingress packets
appropriately.
To access the Queue Config page, click ADVANCED > Quality of Service > Queue
Config or click the Queue Config button.
Wireless ADSL2+ Gateway 78
