Operating Information
2-10
CSA7404B, TDS7704B, TDS7404B, TDS7254B & TDS7154B Service Manual
The following illustration shows the input/output connectors and floppy disk
drive location.
Floppy disk drive
Recovered clock output
Optical input
O/E converter electrical output
Probe compensation
output
Ground terminal
Channel
inputs
Recovered data output
Floppy disk drive
Auxiliary trigger input
Auxiliary trigger output
CH 3 SIGNAL
OUTPUT; scale and
offset controlled by
CH3 controls
Probe compensation
output
Ground terminal
Channel
inputs
CSA7000B Series
TDS7000B Series
Front Panel I/O Map
