Command Descriptions
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
2-113
Table 2- 35: XY format pairs
X-Axis source Y-Axis source
Ch1 Ch2, Ch3, or Ch4
Ref1 Ref2, Ref3, or Ref4
GATEdxyz displays XY signals only when the Z (gating) channel is true. Gated
XYZ is similar to analog oscilloscope modulated XYZ mode except that the
displayed XY signal is either on or off; there is no intensity modulation. Gated
XYZ is useful for showing constellation diagrams. Use the DISplay:XY:ZCHan-
nel and DISplay:XY:ZLEVel commands to specify the Z channel and Z channel
threshold level.
VECtorscope sets the display to a video vectorscope display mode. TDS3VID,
TDS3SDI only.
DISPLAY:XY:MODe OFF
Selects a voltage versus time format for the display.
DISPLAY:XY:MODe?
might return :DISPLAY:XY:MODE TRIGGER indicating a triggered XY display
format.
DISplay:XY:YCHannel, DISplay:XY:YREF, DISplay:XY:ZCHannel,
DISplay:XY:ZLEVel, D ISplay:FORMat
DISplay:XY:YCHannel
Specifies the Y channel to be displayed with channel 1 in T riggered XY display
mode.
Display
DISplay:XY:YCHannel { CH2 | CH3 | CH4 | OFF }
DISplay:XY:YCHannel?
CH2 , CH3,andCH4 specify the channel displayed with channel 1 in Triggered XY
Display mode.
Examples
Related Commands
Group
Syntax
Arguments
