Limit Test Commands
(Requires TDS3LIM)
The Limit Test commands let you automatically compare each incoming
waveform against a template waveform. You set an envelope of limits around a
waveform and let the oscilloscope find the waveforms that fall outside those
limits. When it finds such a waveform, it can generate a hard copy, emit a beep,
save the waveform to memory, stop and wait for your input, or any combination
of these actions. Table 2--15 lists the limit test commands, which are only
available when a TDS3LIM Limit Test application module is installed in the
oscilloscope.
Table 2- 15: Limit Test commands
Header Description
LIMit?
Returns all limit testing parameters
LIMit:BEEP
Beeps when limit exceeded
LIMit:BELl
Same as LIMit:BEEP
LIMit:COMpare:CH<x> Template to compare waveform to
LIMit:HARDCopy Prints a hard copy when limit exceeded
LIMit:SAVEWFM Save waveform to memory storage device
LIMit:STATE Turn limit testing on or off
LIMit:STOPOnviolation Sets or returns the stop on violation mode
LIMit:TEMPLate Template to compare waveform to
LIMit:TEMPLate:DESTination Reference storage for template waveform
LIMit:TEMPLate:SOUrce Template waveform source
LIMit:TEMPLate:TOLerance:
HORizontal
Tem plate horizontal tolerance
LIMit:TEMPLate:TOLerance:VERTical Template vertical tolerance
