Tektronix TDS3000 Series Program Manual

Command Groups
2-20
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
Table 2- 13: Horizontal commands (cont.)
Header Description
HORizontal:SCAle Same as HORizontal:MAIn:SCAle
HORizontal:SECdiv Same as HORizontal:MAIn:SCAle
HORizontal:TRIGger:POSition Time base trigger position
ZOOm:HORizontal:POSition Values are 0 to 100, in percent of record
ZOOm:HORizontal:SCAle Sets or returns the horizontal scale when in
zoom
ZOOm:STATE Activates the zoom function
ITU601 Digital Video Commands
(TDS3SDI Only)
Table 2--14 lists the ITU601 commands available when a TDS3SDI 601 Digital
Video application module is installed in a TDS3000B or TDS3000C Series
oscilloscope.
Table 2- 14: ITU601 commands
Header Description
ITU601:AUTOSet
Sets the instrument to automatically acquire
and display a 601 digi tal video signal
ITU601:EDH RESEt
Sets the EDH error count to zero
ITU601:EDH:COUNt
Sets or returns the state of the EDH error
counter
ITU601:EDH:DETect?
Returns the state of the EDH detect ion
ITU601:EDH:NUMERRors?
Returns the number of 601 digital video EDH
errors
ITU601:INPUT:FORMat
Sets or returns the digital video signal input
format (525 or 625)
ITU601:INPUT:SIGnalstrength?
Returns the digital video signal strength
ITU601:INPUT:STATE?
Returns the input signal state
ITU601:OUTput:FORMat
Sets or returns the format for displaying the
digital video signal com ponents.
