Getting Started
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
1-7
Connector Locations
Figure 1--7 shows the location of the installed communication module, as well as
the rear-panel connectors. The built-in Ethernet port and External trigger are only
available with the TDS3000B and TDS3000C Series models.
Communication Module
Power input
Parallel printer port
TDS3000/TDS3000B
Ethernet port
TDS3000B/TDS3000C
External trigger
TDS3000B/TDS3000C
DC power output
TDS3000/TDS3000B
+14.2 V DC
≤400 mA
Ground terminal
CAL switch
Figure 1- 7: Communication module location
