TDS3000, TDS3000B, and TDS3000C Series Programmer Manual

TRIGger:A:VIDeo:LINE <NR1>

TRIGger:A:VIDeo:LINE?

<NR1> is an integer number that sets the video line number on which to trigger.

The following table lists the valid choices depending on the active video

standard:

Table 2- 41: Video trigger line range

values

Video standard Valid line range

525/NTSC 1-525

625/PAL, SECAM 1-625

Custom 1-3000

HDTV: 1080

720

480

1--1125

1--750

1--525

TRIGGER:A:VIDEO:LINE 23

sets the oscilloscope to trigger on video signal line 23.

TRIGger:A:VIDeo:SCAN

(Requires TDS3VID or TDS3SDI)

Sets or returns the video trigger horizontal line scan rate. This is equivalent to

selecting the Scan Rate bottom-menu item in the Cu stom video menu.

Trigger

TRIGger:A:VIDeo:SCAN { RATE1 | RATE2 | RATE3 | RATE4 | RATE5 }

TRIGger:A:VIDeo:SCAN?

Syntax

Arguments

Examples
