Command Descriptions
2- 292
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
TRIGger:A:VIDeo:FIELD { ODD | EVEN | ALLFields | ALLLines |
FIELD1 | FIELD2 | NUMERic }
TRIGger:A:VIDeo:FIELD?
ODD specifies to trigger on interlaced video odd fields.
EVEN specifies to trigger on interlaced video even fields.
ALLFields specifies to trigger on the interlaced video odd fields.
ALLLines specifies all video lines.
FIELD1 specifies interlaced video field 1. Same as odd.
FIELD2 specifies interlaced video field 2. Same as even.
NUMERic specifies to trigger on the video signal line specified in the
TRIGger:A:VIDeo:LINE command. TDS3VID, TDS3SDI only
TRIGGER:A:VIDEO:FIELD1
selects field 1.
TRIGger:A:VIDeo:HDTV:FORMat
(Requires TDS3VID or TDS3SDI)
Sets or queries the analog HDTV video signal format on which to trigger.
Trigger
TRIGger:A:VIDeo:HDTV”FORMat { HD1080I50 | HD1080I60 | HD1080P24 |
HD1080P25 | HD1080SF24 | HD480P60 | HD720P60 }
TRIGger:A:VIDeo:HDTV:FORMat?
Available HDTV formats are:
Table 2- 40: HDTV formats
HDTV format Description
1080I50 1125 Lines (1080 active), 1920 x 1080 pixel, interlaced, 60 fps
1080I60 1125 li nes (1080 active), 1920 x 1080 pixel, interlaced, 50 fps
1080P24 1125 lines (1080 active), 1920 x 1080 pixel, progressive, 24 fps
Syntax
Arguments
Examples
Group
Syntax
Arguments
