Command Groups
2-14
TDS3000, TDS3000B, and TDS3000C Series Programmer Manual
Table 2- 6: Calibration and diagnostic commands (cont.)
Header Description
DIAg:RESUlt:FLAg? Returns the PASS or FAIL status from the last
FAIL diagnostic test sequence results
DIAg:RESUlt:LOG? Return diagnostic test sequence results
DIAg:SELect:ALL Diagnostics will be run on all subsystems
DIAg:STATE EXECute Executes all the diagnostics tests that have
been selected
Cursor Commands
Cursor commands provide control over cursor (caliper) display and readout.
Table 2--7 lists these commands.
Table 2- 7: Cursor commands
Header Description
CURSor? Query returns all current cursor settings
CURSor:FUNCtion Sets or returns the cursor type
CURSor:GRATicule? Returns XY cursor settings
CURSor:GRATicule:SELect Selects (makes active) the specified graticule
XY cursor
CURSor:GRATicule:XPOSITION<x> Sets or returns the X position of the specified
graticul e cursor
CURSor:GRATicule:YPOSITION<x> Sets or returns the Y position of the specified
graticul e cursor
CURSor:HBArs? Returns horizontal bar settings
CURSor:HBArs:DELTa? Returns vertical distance between horizontal
bars
CURSor:HBArs:POSITION<x> Position a horizontal cursor, relative to ground,
typically in volts
CURSor:HBArs:SELect Sets which horizontal cursor is active
(selected)
CURSor:HBArs:UNIts Sets or returns measurement units for the
horizontal cursors
CURSor:HBArs:USE Sets measurement scale for the horizontal
cursors
CURSor:MODe Sets cursor tracking mode
