Tenda F6 User Manual

26
6 Wireless settings
This module enables you to customize a WiFi name and password, hide your WiFi network so that
the wireless clients cannot detect the WiFi name, set up a WiFi schedule to turn on/off your WiFi
network regularly, and modify wireless parameters.
Click Wireless Settings to enter the configuration page.
Parameter description
Parameter
Description
WiFi Name and
Password
2.4 GHz
Network
Used to enable/disable the wireless network of the router.
WiFi Name
It specifies the wireless network name (SSID) of the WiFi network.
Security Mode
It specifies the encryption modes supported by the router, including:

None: It indicates that a wireless network is not encrypted and any
clients can access the network without a password. This option is
not recommended as it leads to low network security.

WPA-PSK: It indicates that WPA-PSK is adopted to authenticate
users.

WPA2-PSK: It indicates that WPA2-PSK is adopted to authenticate
users.

Tenda F6 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Product type	Tabletop router
Product color	White
LED indicators	WLAN
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Frequency band	2.4 GHz
Firewall security	Support Oray.com，88ip
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Certification	CCC, CE
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
DSL WAN	No
WAN connection type	RJ-45
Power source type	DC
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	211 mm
Width	204 mm
Height	147.5 mm
