Tenda F6 User Manual

33
8.3 Example of configuring parental control
Tom uses F6 to set up a network in his apartment. He wants his daughter Sindy to focus on her
homework from 20:00 to 22:00 instead of YouTube video on weekdays.
The parental controls function can meet this requirement.
Configuration procedure:
Step 1 Choose Parental Controls to enter the configuration page.
Step 2 Click to the state corresponding to Sindy’s phone.
Step 3 Set Allow access during to the period when the device is allowed to access video
websites, which is 20:00-22:00 in this example.
Step 4 Set the date on which the rule takes effect, which is Monday to Friday in this example.
Step 5 Set Website Restrictions to Only Forbid.
Step 6 Set Blocked Websites to www.youtube.com, and click .
Step 7 Click OK at the bottom of the page.
---End
After the settings take effect, Sindy’s smart phone cannot access YouTube from 20:00 to 22:00 on
weekdays.

Tenda F6 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Product type	Tabletop router
Product color	White
LED indicators	WLAN
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Frequency band	2.4 GHz
Firewall security	Support Oray.com，88ip
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Certification	CCC, CE
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
DSL WAN	No
WAN connection type	RJ-45
Power source type	DC
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	211 mm
Width	204 mm
Height	147.5 mm
