Tenda F6 User Manual

50
10.4 Remote web-based management
Generally, the web UI of the router can only be accessed on devices that are connecting to the
router by a LAN port or wireless connection. When you encounter network faulty, you can ask
technician far away to diagnose and fix your problems, improving efficiency and reducing costs and
efforts. By default, it is disabled. When you enable it, it displays as the following figure.
Configuring remote web-based management
Configuration procedure:
Step 1 Choose Administration, and move to Remote Web-based Management module to enter
the configuration page.
Step 2 Select the Enable option.
Step 3 Set Management IP Address to Specific, and enter a specified IP address.
Step 4 Enter a port number used to access the router remotely.
Step 5 Click OK at the bottom of the page.
---End
Parameter Description:
Parameter
Description
Remote Web-based
Management
To enable/disable Remote Web-based Management function. It is disabled by
default.
Management IP Address
It specifies the IP address to manage the router remotely.

All: It indicates that all internet users can access the web UI of the router. It is
not recommended to select this option for network security.

Specific: It indicates that only the host with the specified public IP address is
allowed to access the web UI of router remotely. If the host for remote access is
in an intranet, enter the public IP address of the computer’s gateway here.

Tenda F6 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Product type	Tabletop router
Product color	White
LED indicators	WLAN
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Frequency band	2.4 GHz
Firewall security	Support Oray.com，88ip
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Certification	CCC, CE
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
DSL WAN	No
WAN connection type	RJ-45
Power source type	DC
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	211 mm
Width	204 mm
Height	147.5 mm
