Tenda F6 User Manual

28
6.1 Customizing your WiFi name and password
Step 1 Click Wireless Settings to enter the page, and locate to WiFi Name and Password module.
Step 2 Customize your WiFi name, such as Tenda WiFi.
Step 3 Set Security Mode to WPA/WPA2-PSK Mixed for better security and compatibility.
Step 4 Specify your WiFi Password, such as 123456789.
Step 5 Click OK at the bottom of the page.
---End
When the configuration is completed, you need to re-connect to the new WiFi network with your
wireless devices using the new password.
6.2 Setting up WiFi schedule
Step 1 Choose Wireless Settings to enter the page, and move to WiFi Schedule module.
Step 2 Set WiFi Schedule to Enable.
Step 3 Specify a time period to turn off WiFi network.
Step 4 Choose the specified date to turn off WiFi network.
Step 5 Click OK at the bottom of the page.
---End

Tenda F6 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Product type	Tabletop router
Product color	White
LED indicators	WLAN
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Frequency band	2.4 GHz
Firewall security	Support Oray.com，88ip
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Certification	CCC, CE
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
DSL WAN	No
WAN connection type	RJ-45
Power source type	DC
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	211 mm
Width	204 mm
Height	147.5 mm
