Tenda F6 User Manual

39
9.3 Port forwarding
By default, internet users cannot access any service on any of your local hosts. If you want to
enable internet users to access a particular service on a local host, enable this function and specify
the IP address and service port of the local host. This can also prevent local network from being
attacked when the internal server is opened to the internet users.
Click Advanced, and move to Port Forwarding module to access the configuration page.
Parameter Description:
Parameter
Description
Internal IP
Address
It specifies the IP address of a server that resides on the LAN.
Internal Port
It specifies the service port number of the internal server.
External Port
It specifies a service port number for internet users to access a specified service.
Protocol
It specifies the protocol that specified service uses. Both indicates that both TCP and
UDP are used. If you are uncertain about it, Both is recommended.
Operation
It allows you to manually add and delete a port forwarding rule.
Example of configuring a port forwarding rule
Tom uses a F6 to set up home network, and establishes a web server in LAN. Now he wants
internet users to access the resources on the server. The port forwarding function can be enabled
to fulfill the requirement.
WAN IP address of the
router: 102.33.66.88
Computer 2
Computer 1 (web server)
IP address: 192.168.0.100
Ethernet cable
Ethernet cable
Internet

Tenda F6 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Product type	Tabletop router
Product color	White
LED indicators	WLAN
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Frequency band	2.4 GHz
Firewall security	Support Oray.com，88ip
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Certification	CCC, CE
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
DSL WAN	No
WAN connection type	RJ-45
Power source type	DC
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	211 mm
Width	204 mm
Height	147.5 mm
